Professional LCD& LCM manufacturer Catalogue

Short Description:

1.Large Variety Kerunxinda has a full series of IPS products, unique transflect

Product Details

Product Tags

1.Large Variety

Kerunxinda has a full series of IPS products, unique transflective products， wide temperature prodcuts and self-developed TN products, with different size and resolution.

2.No MOQ

"No MOQ" is the company's outstanding advantage. Based on the market capacity, we always keep products in stock and regard a piece for a PO as a good order. We treat every customer equally, effectively support developing the project with long cycle and little consumption, thus well received by the customers in medical treatment, industrial control and smart homes.

LCD& LCM Catalogue

Size (inch)	Resolution	LCD Type	Interface	Luminance (nits) without Touch	Viewing Angle	Touch Screen	Active Area (mm)	IC Model
0.96	80×160	IPS	4 Line SPI	450	ALL	—	20.48×40.96	ST7735S
1.3	240×240	IPS/round	MCU/SPI/RGB	470	ALL	CTP	23.40×23.40	ST7789V
1.4	128×160	IPS	MCU/SPI/RGB	470	ALL	—	23.40×23.40	ST7789V
1.4	128×128	TN	MCU/SPI	450	6H	RTP	25.50×26.50	ST7735S
1.4	128×128	IPS	MCU/SPI	950	ALL	RTP	25.50×26.50	ST7735S
1.5	240×240	IPS/round	MCU/SPI/RGB	400	ALL	CTP	27.72×27.72	ST7789V
1.6	400×400	IPS/round	MIPI	350	ALL	CTP	39.84×39.84	ST7797
1.8	128×160	TN	MCU/SPI	400	12H	RTP/CTP	28.03×35.04	ST7735S
1.8	240×320	IPS	MCU/SPI/RGB	450	ALL	RTP/CTP	26.64×35.52	ST7789V
1.8	240×320	Transflective	MCU/SPI/RGB	550	ALL	RTP/CTP	26.64×35.52	JD9852
1.8	296×222	Transflective	MIPI	800	ALL	RTP/CTP	35.52×26.64	SSD2119
1.9	128×160	IPS	SPI/MCU	1000	ALL	RTP/CTP	31.872×39.84	ST7735
2	176×220	TN	MCU/SPI	220	ALL	RTP	31.68×39.60	ST7775R
2	240×320	TN	MCU/SPI/RGB	500	12H	RTP	30.60×40.80	ST7789V
2	240×320	Transflective	MCU/SPI/RGB/MIPI	250	ALL	RTP/CTP	30.60×40.80	ST7789V
2	240×320	IPS	MCU/SPI/RGB/MIPI	350	ALL	RTP/CTP	30.60×40.80	ST7789V/JD9852
3.2	320×240	IPS	MCU/SPI/RGB	600	ALL	RTP/CTP	40.80×30.60	ILI9342C
3.2	320×240	Transflective	MCU/SPI/RGB	350	ALL	RTP/CTP	40.80×30.60	ILI9342C
3.2	480×320	IPS	MCU/SPI/RGB/MIPI	900	ALL	RTP/CTP	40.80×30.60	ST7701S
2.1	480×480	IPS/round	SPI+RGB/MIPI	550	ALL	CTP	53.28×53.28	ST7701S
2.2	240×320	TN	8/16 MCU	280	6H	RTP/CTP	33.84×44.64	ST7789V
2.2	240×320	TN	MIPI	450	6H	RTP/CTP	33.84×45.12	JD9852
2.2	240×320	IPS	8/16 MCU	450	ALL	RTP/CTP	33.84×45.12	ER61516
2.2	240×320	Banaview	MCU/SPI/RGB	450	ALL	RTP/CTP	33.84×45.12	ST7789V
2.3	320×240	TN	MCU/SPI/RGB	300	12H	RTP/CTP	46.75×35.06	ILI9342C
2.4	240×320	TN	MCU/SPI/RGB	300	12H	RTP/CTP	36.72×48.96	ST7789V
2.4	240×320	IPS	MCU/SPI/RGB	580	ALL	RTP/CTP	36.72×48.96	ST7789V
2.4	240×320	Transflective	MIPI	550	ALL	RTP/CTP	36.72×48.96	JD9852
2.4	320×480	IPS	MCU/SPI/RGB/MIPI	300	ALL	RTP/CTP	36.72×48.96	ST7789V
2.4	320×480	Transflective	MCU/SPI/RGB/MIPI	750	ALL	CTP	33.12×49.68	ST7701S
2.4	480×640	IPS	SPI+RGB/MIPI	650	ALL	CTP	36.72×48.96	ST7796S
2.4	480×640	IPS	SPI+RGB/MIPI	800	ALL	CTP	36.72×48.96	ST7701S
2.4	800×480	LTPS	8/18 LVDS	1100	ALL	CTP	52.32×31.39	HX8283-A
2.5	480×480	LTPS	18/24 RGB	1100	ALL	CTP	52.32×31.39	HX8283-A
2.5	480×480	IPS/round	MIPI	450	ALL	/	62.64×62.64	ST7701S
2.5	480×480	IPS/round	16/18/24 RGB	450	ALL	/	62.64×62.64	ST7701S
2.6	1280×720	IPS	6/8 BIT LVDS	1300	ALL	CTP	57.6×32.4	SC5014
2.6	240×320	TN	MCU/SPI/RGB	500	6H	RTP/CTP	38.11×51.84	ST7789V
2.6	240×320	IPS	MCU/SPI/RGB/MIPI	350	ALL	RTP/CTP	39.60×52.80	ST7789V/JD9852
2.6	320×432	TN	MCU/SPI/RGB	300	12H	RTP/CTP	52.80×39.60	ILI9342C
2.6	320×432	Transflective	MCU/SPI/RGB	500	ALL	RTP/CTP	39.84×53.12	ILI9488
2.7	320×240	TN	SPI/RGB	800	12H	RTP/CTP	54.00×40.50	ILI8961
2.7	320×240	IPS/round	MCU/SPI/RGB/MIPI	900	ALL	RTP/CTP	48.96×36.72	ST7796
2.8	240×320	TN	MCU/SPI/RGB	450	12H	RTP/CTP	43.20×57.60	ST7789V
2.8	240×320	IPS	MCU/SPI/RGB/MIPI	700	ALL	RTP/CTP	43.20×57.60	ST7789V/JD9852
2.8	240×320	Transflective	MCU/SPI/RGB/MIPI	1200	ALL	CTP	36.72×48.96	ILI9327
2.8	480×640	IPS	SPI+RGB/MIPI	750	ALL	CTP	43.20×57.60	ST7701S
2.8	480×640	IPS/square	SPI+RGB/MIPI	500	ALL	CTP	70.13×70.13	ST7701S
2.9	376×960	IPS	SPI+RGB/MIPI	550	ALL	CTP	26.51×67.68	ST7701S
3	240×400	TN	MCU/SPI/RGB	320	12H	RTP/CTP	38.88×64.80	ILI9327
3	240×400	IPS	MCU/SPI/RGB/MIPI	400	ALL	RTP/CTP	38.88×64.80	ST7796S
3	480×854	IPS	SPI+RGB/MIPI	400	ALL	CTP	36.72×65.28	ST7701S
3	360×640	IPS	2SPI+RGB/MIPI	340	ALL	CTP	36.72×65.28	ST7701S
3	268×800	IPS	SPI+RGB/MIPI	750	ALL	CTP	24.12×72.00	ST7701S
3.1	480×800	IPS	24 RGB/MIPI	350	ALL	CTP	40.32×67.2	ST7701S
3.2	240×320	TN	MCU/SPI/RGB/MIPI	450	6H	RTP/CTP	48.60×64.80	ST7789V/JD9852
3.2	240×320	IPS	MCU/SPI/RGB/MIPI	500	ALL	CTP	48.60×64.80	ST7789V
3.2	480×640	IPS	SPI+RGB/MIPI	850	ALL	RTP/CTP	49.25×65.60	ST7701S
3.4	480×480	IPS	SPI+RGB/MIPI	1000	ALL	CTP	60.48×60.48	ST7701S
3.4	800×800	IPS	MIPI/LVDS	450	ALL	CTP	87.60×87.60	ILI9881C/NV3051F-L
3.5	320×240	TN	MCU/SPI/RGB	480	12H	RTP/CTP	70.08×52.56	ST7796
3.5	320×240	IPS	RGB	920	ALL	RTP/CTP	70.08×52.56	ST7272A
3.5	640×480	IPS	SPI+RGB/MIPI	750	ALL	RTP/CTP	70.08×52.56	NV3052C
3.5	240×320	TN	MCU/SPI/RGB	120	12H	RTP/CTP	53.28×71.04	ILI9325C
3.5	240×320	IPS	MCU/SPI/RGB	120	ALL	RTP/CTP	53.28×71.04	HX8347A
3.5	240×320	Transflective	MCU/SPI/RGB	120	6H	RTP/CTP	53.28×71.52	ILI9341
3.5	320×480	TN	MCU/SPI/RGB	300	12H	RTP/CTP	48.96×73.44	ILI9486
3.5	320×480	IPS	MCU/SPI/RGB	600	ALL	RTP/CTP	48.96×73.44	ST7796S
3.5	480×640	Transflective	SPI+RGB/MIPI	120	Wide angle	CTP	53.57×71.42	HX8363A
3.5	480×640	Banaview	SPI+RGB/MIPI	1550	VA	CTP	53.28×71.04	ILI9806E
3.5	340×800	IPS	SPI+RGB	400	ALL	/	33.97×81.00	ST7701S
3.5	480×800	IPS	SPI+RGB/MIPI	500	ALL	CTP	45.36×75.60	ST7701S
3.5	640×960	IPS	SPI+RGB/MIPI	400	ALL	CTP	49.92×74.88	NV3052C
3.6	544×506	IPS	RGB	900	ALL	/	89.76×83.49	ST72566
3.8	1024×600	IPS	RGB/LVDS	900	ALL	CTP	82.64×48.42	JD9168

3.9	480*128	TN	24BIT RGB	500	12H	/	95.04*25.34	/
4	480*800	IPS	MCU/SPI/RGB/MIPI	520	ALL	RTP/CTP	51.84*86.40	NT35510MH/ST7701S
4	320*320	IPS/ square	MCU/SPI/RGB/MIPI	950	ALL	CTP	71.14*69.82	ST7796
4	480*480	IPS/ square	SPI+RGB/MIPI/LVDS	1000	ALL	RTP/CTP	71.86*70.18	ST7701S
4 4	720720 720720	IPS/ square IPS/ round	SPI+RGB/MIPI MIPI	700 900	ALL ALL	RTP/CTP /	71.9371.93 101.52101.52	ST7703 ILI9881C
4	400*960	IPS	SPI+RGB/MIPI	500	ALL	CTP	39.18*94.03	ST7701S
4	1920*1080	IPS	LVDS	1200	ALL	CTP	88.58*49.83	SC5010

4.3	480*272	TN	RGB	350	12H	RTP/CTP	95.04*53.86	NV3047E
4.3	480*272	IPS	RGB	900	ALL	RTP/CTP	95.04*53.86	SC7283
4.3	800*480	IPS	RGB/LVDS	1260	ALL	RTP/CTP	95.04*53.86	ST7262
4.3	480*800	IPS	SPI+RGB/MIPI	450	ALL	RTP/CTP	56.16*93.60	ILI9806E
4.3	480*800	IPS	MCU	450	ALL	RTP/CTP	56.16*93.60	ILI9806

4.5	480*854	TN	SPI+RGB/MIPI	310	12H	RTP/CTP	55.44*98.64	ILI9806E
4.5	1920*1080	IPS	LVDS	1300	ALL	CTP	98.496*55.404	Sc5010

5	800*480	TN	RGB	350	12H	RTP/CTP	108.0*64.80	ILI5960/ILI6122
5	800*480	IPS	RGB/LVDS	650	ALL	RTP/CTP	108.0*64.80	ST7262
5	1920*1080	IPS	MIPI/LVDS	1000	ALL	CTP	110.59*62.20	SC5010E/SC5010B
5	480*854	IPS	MCU/SPI/RGB/MIPI	520	ALL	RTP/CTP	61.63*109.65	ILI9806/ILI9806E
5	720*1280	IPS	MIPI	520	ALL	RTP/CTP	62.10*110.40	ILI9881C
5	1080*1080	IPS/ Round	MIPI	300	ALL	CTP	127.00*127.00	HX8399

5.5	720*1280	IPS	MIPI/LVDS	700	ALL	CTP	68.04*120.96	ILI9881C/NV3051F-L
5.5	1080*1920	IPS	MIPI	400	ALL	CTP	68.04*120.96	HX8399-A
5.6	640*480	TN	RGB	450	12H	RTP/CTP	112.90*84.67	/

*5.7	640*480	IPS	RGB	600	ALL	CTP	115.2*86.4	JD9168S

5.8	1280*768	IPS	LVDS	1000	ALL	CTP	126.72*74.88	/
5.8	1920*1080	IPS	LVDS	1000	ALL	CTP	126.72*71.28	/

5.9	840*512	IPS	RGB/MIPI/LVDS	950	ALL	RTP/CTP	127.16*77.88	JD9168S

6	720*1440	IPS	MIPI	560	ALL	CTP	68.04*136.08	ILI9881C
6	720*1280	IPS	MIPI/LVDS	400	ALL	CTP	73.98*131.52	ILI9881C/NV3051F-L

6.2	640*240	IPS	RGB	900	ALL	RTP/CTP	148.80*53.76	ST5043AA/ST5894AA
6.6	1080*2408	IPS	MIPI	550	ALL	CTP	68.43*152.57	FT8725

6.7	1080*2400	IPS	MIPI	400	ALL	CTP	70.08*155.74	ICNL9922CAC-01
6.7	1920*1080	IPS	LVDS	800	ALL	CTP	148.32*83.43	/

*6.8	480*1280	IPS	MIPI/LVDS	2350	ALL	CTP	60.19*160.51	ICNL9707;73271
6.8	800*480	IPS	RGB	800	ALL	/	148.10*88.86	3123
7	800*480	TN	RGB	450	12H	RTP/CTP	154.08*85.92	EK9713/EK7330
7	800*480	IPS	RGB/LVDS	400	ALL	RTP/CTP	152.40*91.44	/
7	1024*600	IPS	RGB/LVDS/MIPI	600	ALL	RTP/CTP	154.21*85.92	/
7	1200*1920	IPS	MIPI	450	ALL	CTP	94.5*151.2	R69429
7	720*1280	IPS	MIPI/LVDS	1200	ALL	CTP	86.94*154.56	ILI9881C
7	720*1440	IPS	LVDS	400	ALL	CTP	78.02*156.04	GC9704
7	800*1280	IPS	MIPI	450	ALL	CTP	94.20*150.72	ILI9881C
7	280*1424	IPS	MIPI	650	ALL	CTP	33.60*170.88	OTA7290N

7.8	400*1280	IPS	RGB/MIPI	1100	ALL	CTP	59.40*190.08	GC9703C/GC9704C

8	800*600	TN	24RGB	250	6H	RTP/CTP	162.0*121.5	/
8	1024*768	TN	LVDS	550	6H	CTP	162.05*121.54	/
8	1600*480	IPS	LVDS	480	ALL	CTP	194.40*58.32	/
8	1920*1200	IPS	LVDS	1500	ALL	CTP	172.22*107.64	/
8	800*1280	IPS	MIPI/LVDS	450	ALL	CTP	107.64*172.22	ILI9881C/NV3051F-L
8	1200*1920	IPS	MIPI	350	ALL	CTP	107.64*172.22	NT51021B

8.9	480*1920	IPS	MIPI	850	ALL	CTP	54.72*218.88	OTA7290N

9	1280*720	IPS	LVDS	1000	ALL	CTP	198.91*111.89	/
9	800*480	TN	RGB	300	12H	RTP/CTP	198.0*111.7	/
9	1024*600	IPS	RGB/LVDS/MIPI	1000	ALL	RTP/CTP	196.61*114.15	EK73215&EK79001

9.7	1024*768	IPS	LVDS	250	ALL	CTP	196.6*147.46	/

9.8	1280*320	TN	LVDS	1300	6H	/	241.15*60.29	/

10	1200*1600	IPS	MIPI	反射率13.5%	ALL	/	152.46*203.28	HX8279*2

10.1	1024*600	IPS	RGB/LVDS/MIPI	550	ALL	CTP	222.72*125.28	/
10.1	1280*720	IPS	LVDS	650	ALL	CTP	223.68*125.82	/
10.1	1280*800	IPS	LVDS	800	ALL	CTP	216.96*135.60
10.1	1920*1200	IPS	LVDS	500	ALL	CTP	216.81*135.5	HX8290-B,ILI2511
10.1	440*1920	IPS	MIPI	750	ALL	CTP	57.948*252.864	ICNL9707
10.1	800*1280	IPS	MIPI	400	ALL	CTP	135.36*216.58	LI9881C
10.1	1200*1920	IPS	MIPI	380	ALL	CTP	135.36*216.58	HX8279D

10.4	800*600	TN	24 RGB	250	6H	CTP	211.20*158.4	/
10.4	1024*100	TN	24 RGB	1000	12H	/	264.192*25.8	HX8282,Hx8678
10.4	1024*768	IPS	MIPI/LVDS	1500	ALL	CTP	210.43*157.82	/

11.6	1920*1080	IPS	eDP	1100	ALL	CTP	256.32*144.18	/
11.6	3840*2160	IPS	eDP	550	ALL	CTP	256.90*144.50
12.1	1024*768	IPS	LVDS	800	ALL	CTP	245.7618432	/
12.1	1280*800	IPS	LVDS	1000	ALL	CTP	261.12*163.2	/

12.2	1280*800	IPS	LVDS	400	ALL	/	262.656*164.16	HX8245-E04

12.3	1920*720	IPS	LVDS	850	ALL	CTP	292.032*109.512	/

12.8	1920*1080	IPS	LVDS	700	ALL	CTP	283.392*159.408	/

13.3	1920*1080	IPS	eDP/LVDS	1250	ALL	CTP	293.47*165.07	/

13.5	1280*235	IPS	LVDS	1000	ALL	CTP	337.92*62.04	/

13.9	1280*400	IPS	LVDS	1400	ALL	/	337.92*105.14	HX8249/HX8678

14	1600*900	TN	RGB	250	6H	CTP	309.6*174.15	/
14	1920*1080	IPS	eDP	800	ALL	/	308.16*173.34	/

14.5	2560*720	IPS	LVDS	800	ALL	/	355.50*100.00	/

15	1024*768	IPS	LVDS	500	ALL	/	304.10*228.10	/
15	1280*272	IPS	LVDS	1000	ALL	/	374.79*70.86	/

15.6	1920*1080	IPS	eDP/LVDS	1000	ALL	CTP	344.16*193.59	1

16.7	1920*540	IPS	LVDS	1200	ALL	/	408.96*115.02

17	1280*1024	IPS	LVDS	250	ALL	/	337.92*270.3	/
17	1280*960	IPS	LVDS	240	ALL	/	345.41*259.06	/

18.5	1366*768	TN	LVDS	250	6H	/	409.8*230.4	/
18.5	1920*1080	IPS	LVDS	350	ALL	/	408.96*230.04	/

19	1400*900	TN	LVDS	220	6H	/	408.24*255.15	/
19	1280*1024	IPS	LVDS	245	ALL	/	376.32*301.05	/

20.8	1920*184	IPS	LVDS	500	ALL	/	527.04*50.6	/

21.5	1920*1080	IPS	LVDS	800	ALL	/	476.06*267.8	/

23.6	1920*1080	IPS	LVDS	1000	ALL	/	521.28*293.22	/

27	1920*1080	IPS	LVDS	800	ALL	/	597.888*336.312	1
27	2560*1440	IPS	LVDS	550	ALL	/	596.74*335.66	/
27	3840*2160	IPS	eDP	1200	ALL	/	596.74*335.66	/

28	1920*360	IPS	LVDS	700	ALL	/	698.40*130.95	/

31.5	1920*1080	IPS	LVDS	1000	ALL	/	698.4*392.85	/

32	1920*1080	IPS	LVDS	1700	ALL	/	394.82*694.61	/

49	3840*2160	IPS	EPI	1500	ALL	/	1073.78*604.01	/

Leave Your Message

Write your message here and send it to us

5.0 Inch TFT LCD Display 720*1280 HDMI‑L

1 Inch Round AMOLED Display 340×340 SH86

1.8 Inch Transflective Blanview LCD 296×

1.3" Small Square IPS TFT Display 2

2.93-inch MIPI Interface IPS Display, 55

[2] | [320*240] | [MCU/SPI/RGB] | [220]n

Professional LCD& LCM manufacturer C

Professional LCD& LCM manufacturer Catalogue

Short Description:

Product Details

Product Tags

2.No MOQ

Leave Your Message

Related PRODUCTS

5.0 Inch TFT LCD Display 720*1280 HDMI‑L

1 Inch Round AMOLED Display 340×340 SH86

1.8 Inch Transflective Blanview LCD 296×

1.3" Small Square IPS TFT Display 2

2.93-inch MIPI Interface IPS Display, 55

[2] | [320*240] | [MCU/SPI/RGB] | [220]n

Professional LCD& LCM manufacturer C

Leave Your Message
